Steptek Quality Extra Heavy Duty Narrow Base Model
Steptek Extra Heavy Duty Narrow Base Model offers a 150kg load capacity, space-saving design, secure hand-lock system, and non-marking feet for stability and safety.
Steptek Quality Extra Heavy Duty Narrow Base Model
Built for demanding tasks, the Steptek Quality Extra Heavy Duty Narrow Base Model is hand-crafted for reliability and built to endure, with a 150kg load capacity. Constructed from heavy-gauge welded steel box sections, it features a secure hand-lock lever anchorage, ensuring the front feet rest firmly on the floor with protective non-marking rubber feet when locked. For added safety, a warning bar extends in front of the steps, linked to the hand lock lever to prevent climbing in 'mobile' mode. Designed with a narrow base and outboard wheels for efficient space-saving, the unit is finished with a durable blue epoxy coating, with safety elements highlighted in yellow. Equipped with two front swivel castors (100mm rubber-tyred wheels with roller bearings) and two rear axle-mounted wheels (200mm diameter), this model provides stable and smooth mobility.
Number of Treads (inc platform) | 3 | 4 | 5 | 6 |
---|---|---|---|---|
Average working height (mm) | 2190 | 2420 | 2650 | 2880 |
Platform height (mm) | 690 | 920 | 1150 | 1380 |
Overall Dimension (H x W x D) (mm) | 1690 x 700 x 930 | 1920 x 700 x 1140 | 2150 x 700 x 1240 | 2380 x 700 x 1410 |
Unit Weight (kg) | Up to 51 | Up to 59 | Up to 69 | Up to 88 |
Number of Treads (inc platform) | 7 | 8 | 9 | 10* |
---|---|---|---|---|
Average working height (mm) | 3110 | 3340 | 3570 | 3800 |
Platform height (mm) | 1610 | 1840 | 2070 | 2300 |
Overall Dimension (H x W x D) (mm) | 2610 x 700 x 1570 | 2840 x 700 x 1740 | 3070 x 700 x 1900 | 3300 x 900 x 2060 |
Unit Weight (kg) | Up to 97 | Up to 107 | Up to 117 | Up to 131 |
Number of Treads (inc platform) | 11* | 12* | 13* | 14* | 15* |
---|---|---|---|---|---|
Average working height (mm) | 4030 | 4260 | 4490 | 4720 | 4950 |
Platform height (mm) | 2530 | 2760 | 2990 | 3220 | 3450 |
Overall Dimension (H x W x D) (mm) | 3530 x 900 x 2230 | 3760 x 900 x 2400 | 3990 x 1230 x 2560 | 4220 x 1230 x 2730 | 4450 x 1230 x 2890 |
Unit Weight (kg) | Up to 140 | Up to 151 | Up to 163 | Up to 175 | Up to 187 |
*10 tread and above supplied in 2 halves for transport purposes.
